Power Train Battery Charger 20 Amp 12V Automatic Multi Stage

20 Amp 12V Automatic Battery Multi-Stage Charging System

Power Train battery chargers are designed to effectively charge all automotive and industrial type batteries. Manufactured to the latest design parameters and highest quality levels; they incorporate a unique microprocessor controlled eight-stage pulse charging system which intelligently assesses battery condition and size to make battery charging much safer, and more effective – thus prolonging battery life.

They are ideal for automotive, motorhome, horse trucks and marine applications ensuring the correct, safest and best method of charging a high capacity 12V battery bank or individual batteries.

Features

• Built in microchip monitoring and charging control system

• Accurate voltage and current detection, monitoring on both AC input and DC output

• Optimally designed charging cycle designed for lead acid, SLA, Gel, deep cycle and calcium batteries

Complete eight stage pulse charging cycle including:

• Desulphation

• Soft start

• Bulk

• Absorption

• Analysis (battery fault diagnosis)

• Boost

• Float

• Maintenance stage

• Automatic adjustment of charging voltages according to environmental temperature

• Overcharge protection – protecting the battery from damage due to overcharging

Protection from:

• Reverse polarity

• Short circuit

• Overload

• High temperature

• LED display simultaneously showing charging voltage, amperage and percentage of battery charge(99% flashing when fully charged)

• Battery testing function while charging (faulty batteries will activate the “faulty battery” indicator L.E.D and the warning alarm)

• Built-in automatic cooling fan
